Drum Mixer

Drum Mixer

Product Introduction

Model：JZM500,JZM750
Productivity(m³/h)：18-35
Maximum Size of Aggregate(mm)：60-80
Discharging Capacity(L): 500-750
Charging capacity(L)： 800-200
Mixer speed( r/min)：15-12.26

Applicatiop: CHAND drum mixer is widely used in construction sites, road construction, bridges, hydropower projects, various concrete component plants and other fields, as well as projects that need to be constructed near residential areas.

CHAND drum mixer has two capacities:500L,750L.

CHAND has an excellent manufacturing team with more than 20 years of experience.

Drum mixer,which has been produced in CHAND for many years and is one of the best-selling batching plants.

JZM500/JZM750 drum mixer is a highly efficient and reliable concrete mixer driven by friction transmission of tugboat.

Drum mixer rotates clockwise for mixing and counterclockwise for discharging.

It is a self-falling discharging method that can easily meet the mixing needs of plastic and semi-dry hard concrete.

All concrete mixer products can be customized to meet your needs and improve productivity and passed ISO9001 quality certification.

If you are looking for an efficient and easy-to-use concrete mixer device, CHAND drum mixer is undoubtedly your best option.

Our equipment has novel structure, beautiful appearance, convenient operation and maintenance, high production efficiency, good mixing quality, easy to move and low noise.

Technical Parameter

Model	JZM750	JZM500
Discharging Capacity(L)	750	500
Charging capacity(L)	1200	800
Productivity（m³/h）	30-35	18-20
Mixer speed( r/min)	12.26	15
Maximum Size of Aggregate(mm)	80	60
Water supply accuracy(%)	error≤2	error≤2
Mixer motor(KW)	2×7.5	2×2.5
Lifting Motor Power(KW)	7.5	5.5
Water Pump Powe(KW)	1.1	1.1
Tire specifications	750-16	700-16

JZM750

JZM500

JZC Series

Drum mobile mixer

Product Features



The use of advanced mixing technology and reasonable structural design ensures that the concrete is fully mixed in the mixing drum, and the mixing speed is fast and uniform.



The operation interface is simple and clear, easy to operate and maintain.



The structure is compact and occupies a small area, which is very convenient to move and transfer between different construction sites.



Strong production capacity, productivity can reach 35m3/h, and high-efficiency mixing.



The mixer drum adopts an advanced 4 rubber tug friction drive system to achieve low noise and efficient operation.



The inner wall of the mixing drum is made of wear-resistant material, which extends the service life of the mixer.

Packaging & Shipping

Each equipment will be thoroughly and strictly inspected before packing to ensure that all parts are intact, and will be accompanied by a detailed operation manual and maintenance guide to ensure that the equipment is delivered to the customer complete and on time.
