Home / Products / SCS Electronic Truck Scale（weighbridge）
SCS Electronic Truck Scale（weighbridge）
Product Introduction
Model：SCS 5t-300t
Maximum Weighing(T)：300
Minimum Weighing(Kg)：200
Applications:SCS Electronic Truck Scale（weighbridge）is Widely used in inbound and outbound materials, inventory measurement, production monitoring and data management for ports, factories, mixing plant, freight yards, storage terminals, workshops, warehouses, etc. It is suitable for weighing and measuring vehicles such as trucks, trailers, semi-trailers and container vehicles.
CHAND‘s electronic truck scale is an advanced steel-framed scale featuring a U-shaped cold-bent channel steel construction for its platform, grouped into multiple closed cavities, so that the truck scale (wagon balance) platform is in overall steel, various performance indexes such as bending resistance and partial compression of the table top have been greatly improved.
Widely used in inbound and outbound materials, inventory measurement, production monitoring and data management for ports, factories, mixing plant, freight yards, storage terminals, workshops, warehouses, etc. It is suitable for weighing and measuring vehicles such as trucks, trailers, semi-trailers and container vehicles.
Product Parameter
Model
SCS 5t-300t
Maximum Weighing
300t
Minimum Weighing
200kg
Test Index
20kg
Actual scale value
10kg
Safety Overload
120%FS
Ultimate Overload
150%FS
Table Thickness
customized
Scale Body Structure
U-beam structure is made of Q235A carbon steel
Main Beam Specification
200mmU-300mm, U-shaped steel beam, carbon steel Q235A material
Foundation Form
Without foundation pit, shallow foundation pit
Accuracy Class
C3, OIML, III (high precision and sensitivity)
Power Supply
220VAC(--15%~+10%), 50HZ±2%
Product Features
High precision and stability
High precision: SCS electronic truck scales use advanced sensor technology and digital signal processing technology to achieve high-precision weighing. This high precision can ensure the accuracy of weighing results, which is particularly important for occasions that require precise measurement.
Strong stability: Its structural design is reasonable, rigid, and strong, and it can maintain stable performance in long-term use. At the same time, the electronic truck scale also has a self-diagnosis function, which can detect and deal with potential problems in a timely manner, further improving its stability.
Fast and efficient
Fast weighing speed: Compared with traditional mechanical truck scales, SCS electronic truck scales weigh faster, usually only a few seconds to complete the weighing of a vehicle. This fast weighing speed can greatly improve work efficiency, especially when a large number of vehicles need to be processed.
High degree of automation: It can be used in conjunction with a computer or weighing software to achieve automated weighing and data processing. This can not only reduce manual operations and avoid human errors, but also save labor costs and improve overall operational efficiency.
Easy to operate and maintain
Easy to operate: The SCS electronic truck scale has a friendly operating interface, complete functions and easy operation. Users only need to follow the operating instructions without complicated training and learning.
Easy to maintain: Its structure is compact and easy to install and move. At the same time, the maintenance of the electronic truck scale is relatively simple, and only regular inspection and maintenance are required.
Anti-corrosion and durable
Strong corrosion resistance: The scale of SCS electronic truck scale is usually made of corrosion-resistant materials such as stainless steel, which can maintain stable performance in harsh environments. This corrosion resistance can ensure that the electronic truck scale will not reduce accuracy or service life due to corrosion during long-term use.
Long service life: Due to its sturdy structure, reasonable design, and high-quality materials and sensor technology, the service life of SCS electronic truck scale is relatively long. This not only reduces the user's replacement costs, but also reduces downtime caused by equipment failure.
Intelligence and networking
Intelligent control: Modern SCS electronic truck scales are usually equipped with intelligent control systems that can realize functions such as remote monitoring, data analysis and fault diagnosis. This intelligent control can further improve the reliability and stability of the equipment.
Network transmission: By connecting to the network, SCS electronic truck scales can transmit weighing data to a remote server or database to achieve real-time data sharing and remote management. This can not only improve the efficiency of data processing, but also provide strong support for corporate decision-making.
Our Service
As a professional manufacturer, we are well aware of the importance of product quality. From material selection to manufacturing, every link of the equipment is strictly controlled. In terms of price, we promise to provide customers with the most competitive factory price, so that customers can enjoy high-quality products while saving costs and improving economic benefits. We always take customer satisfaction as the first criterion. No matter what problems customers encounter during use, we will respond in time and provide professional and effective solutions.
Recently, an Indonesian customer contacted our company’s sales staff on the Internet and reached a cooperation agreement after several communications. According to the customer’s site…
